PLUG1212 Infrared Camera Module
Large Array 1280x1024 / 12μm Uncooled FPA Thermal Imaging Camera
Core for Security & Monitoring
Product Description
PLUG1212 is one of the PLUG series uncooled infrared thermal camera
core developed by Global Sensor Technology (GST) which is a
manufacturer of cooled uncooled infrared detectors and OEM thermal
camera cores.
With the large array 1280x1024 resolution, the PLUG1212 infrared
camera core outputs ultra clear image, presents more image details
and supports larger field of view. The reduced 12µm pixel size
offers better spatial resolution and matches shorter optical lens
focus to achieve the same range mission.
PLUG series infrared thermal cores are specially developed for
various personalized observation requirements, which provide
various standard industrial interfaces and infrared lens options to
meet specific integration requirements. Some professional thermal
imaging solutions have been applied to many applications.
Main Features
- NETD<30mk, High Sensitivity
- Stable Performance
- Clear Image Quality & Details
- Easy Integration & Plug-in
- Strong Environmental Adaptability
Product Specifications
| Model | PLUG1212 |
| IR Detector Performance |
| Resolution | 1280x1024 |
| Pixel Pitch | 12μm |
| Spectral Range | 8~14μm |
| NETD | <30mk |
| Image Processing |
| Frame Rate | 25Hz |
| Start-up Time | <25s |
| Analog Video | / |
| Digital Video | HDMI/RAW/YUV/BT1120 |
| Extension Component | USB/Camerlink |
| Dimming Mode | Linear/Histogram/Mixed |
| Digital Zoom | 1~8X Continual Zoom, Step Size 1/8 |
| Image Display | Black Hot/White Hot/Pseudo Color |
| Image Direction | Horizontally/Vertically/Diagonally Flip |
| Image Algorithm | NUC/AGC/IDE |
| Electrical Specification |
| Standard External Interface | 50pin_HRS Interface |
| Communication Mode | RS232-TTL, 115200bps |
| Supply Voltage | 5±0.5V |
| Typical Power Consumption | <2.0W |
| Physical Characteristics |
| Dimension (mm) | 56x56x40.2 |
| Weight | ≤220g |
| Environmental Adaptation |
| Operation Temperature | -40°C ~ +70°C |
| Storage Temperature | -45°C ~ +85°C |
| Humidity | 5%~95%, Non-condensing |
| Vibration | Random Vibration 5.35grms, 3 Axis |
| Shock | Half-sine Wave, 40g/11ms, 3 Axis 6 Direction |
| Optics |
| Optional Lens | Fixed Focus Athermal: 19mm/25mm |
Industrial Applications
The PLU1212 infrared imaging module is widely used in Security &
Monitoring, Outdoors, Firefighting & Rescue, Law Enforcement &
Rescue, ADAS, UAV Payloads etc.
Our Product Line
FAQs
1.What is infrared thermal imaging?
Infrared thermal imaging is a kind of method which utilizes
infrared radiation and thermal energy to gather information about
objects. According to the radiation difference between the object
and the background environment and the radiation difference of each
part of the object itself, the infrared thermal image can show the
radiation fluctuation of each part of the scene, thus showing the
characteristics of the scene.
2. What is the advantage of infrared thermal imaging?
---See through total darkness;
---Identification under camouflage;
---Long range detection;
---Heat distribution detection;
---Non-contact temperature measurement;
---Occupation awareness
3. What is the applications of infrared thermal imaging?
Temperature measurement and all-weather imaging are two basic
functions of infrared thermal imaging technology. Products
developed based on these two technologies are widely used in
electric power, security & monitoring, industrial manufacturing,
scientific research, medical treatment and other traditional
fields.
