Product Description
C330S LWIR is one of T2SL lwir cooled infrared detectors developed
by Global Sensor Technology (GST). It consists of a 320x256@30µm
Type II Superlattice (T2SL) cooled photon detector, Integrated
Detector Cooler Assembly (IDCA), designed for high performance
7.7~9.5μm Long Wave Infrared (LWIR) wavebands.
Without fear of interference, C330S LWIR cooled lwir detector is
suitable for target detection in complex background, such as ships
on the sea in the scene of light reflection on the water surface,
aircraft in the background of clouds in the sky, etc.
T2SL cooled detectors adopts the world's leading T2SL technology
which enables mass production capability and thus ultimately it
will benefit the users with more affordable price but never
compromise in performance. The industrial standard size and
interface enables customers to switch to and benefit from the most
advanced T2SL technology without further R&D investment.
Main Features:
- Resolution: 320x256
- Pixel Pitch: 30µm
- High Sensitivity
- Good Imaging Effect
- Low Noise
- Stable Performance
- Excellent Non-uniformity
Product Specifications
| Model | C330S LWIR |
| Material | T2SL |
| Resolution | 320x256 |
| Pixel Pitch | 30μm |
| Spectral Range | 7.7μm～9.5μm LW |
| Working Mode | Snapshot; ITR Integration Mode; Windows Mode; Anti-blooming |
| Charge Capacity | 36Me-/12Me- |
| Dynamic Range | ≥80dB |
| Output Channel | 1 or 4; Up to 6.6 Mpixel/s per Output |
| NETD | ≤25mK (F2) |
| Effective Pixel Rate | ≥99.5% |
| Response Non-uniformity | ≤8% |
| Cooler Type | RS058 |
| Steady Power Consumption | <8W |
| Max Power Consumption | <17W |
| Power Supply | 24V DC |
| Cooling Time | <5min30s |
| Weight | ≤600g |
| Dimension (mm) | 142x58.5x71 |
| Working Temperature | -45°C ~ +71°C |
Industrial Applications
The C330S LWIR cryogenically cooled infrared detector is widely
used many areas such as Remote Monitoring System, Flight Vision
Enhancement System, Multi-sensor Payload etc.
Our Advantages
FAQs
1.What is infrared thermal imaging?
Infrared thermal imaging is a method of using infrared radiation
and thermal energy to gather information about objects, in order to
formulate images of them, or get temperature information of the
objects, even in low visibility environments.
2.What is thermography?
Thermography is a non-invasive diagnostic method, based on object
surface temperature detection. The infrared (IR) radiation emitted
from an object is recorded and visualised in the form of a
temperature distribution map. The infrared thermal image can be
used to determine; structural defects, electrical faults,
mechanical faults, physiological changes in people & animals, and
much more.
3.What is the advantage of infrared thermal imaging?
---See through total darkness;
---Identification under camouflage;
---Long range detection;
---Heat distribution detection;
---Non-contact temperature measurement;
---Occupation awareness
