1280x1024 12μm Uncooled VOx Microbolometer Module for Flexible
Thermal Imaging Solutions
Product Description
PLUG1212 uncooled thermal camera core offers thermal images up to
1280x1024 pixels and shows you the smallest of details. Its reduced
12µm pixel size offers better spatial resolution and matches
shorter optical lens focus to achieve the same range mission.
Unlike traditional cooled thermal imaging systems, the uncooled HD
LWIR 1280x1024/12μm VOx Thermal Imaging Module operates without the
need for a cryogenic cooling system. This results in significant
cost reduction, increased portability, and a simplified maintenance
process. The module utilizes a state-of-the-art uncooled
microbolometer sensor based on VOx (Vanadium Oxide) technology,
ensuring reliable and continuous thermal imaging performance.
The compact design of the module, with its dimensions optimized for
easy integration, makes it suitable for installation on drones,
handheld devices, security systems, and other portable platforms.
This lightweight module has been engineered to ensure seamless
integration into existing systems, offering flexibility and
versatility in thermal imaging applications.
PLUG1212 infrared thermal core is applied in a wide range of areas
and its visual information solutions cover day, night, low
visibility and all weather conditions.
Main Features
- Ultra clear thermal imaging
- Stable performance
- Clear Image Quality & Details
- Strong Environmental Adaptability
Product Specifications
| Model | PLUG1212 |
| IR Detector Performance |
| Resolution | 1280x1024 |
| Pixel Pitch | 12μm |
| Spectral Range | 8~14μm |
| NETD | <30mk |
| Image Processing |
| Frame Rate | 25Hz |
| Start-up Time | <25s |
| Analog Video | / |
| Digital Video | HDMI/RAW/YUV/BT1120 |
| Extension Component | USB/Camerlink |
| Dimming Mode | Linear/Histogram/Mixed |
| Digital Zoom | 1~8X Continual Zoom, Step Size 1/8 |
| Image Display | Black Hot/White Hot/Pseudo Color |
| Image Direction | Horizontally/Vertically/Diagonally Flip |
| Image Algorithm | NUC/AGC/IDE |
| Electrical Specification |
| Standard External Interface | 50pin_HRS Interface |
| Communication Mode | RS232-TTL, 115200bps |
| Supply Voltage | 5±0.5V |
| Typical Power Consumption | <2.0W |
| Physical Characteristics |
| Dimension (mm) | 56x56x40.2 |
| Weight | ≤220g |
| Environmental Adaptation |
| Operation Temperature | -40°C ~ +70°C |
| Storage Temperature | -45°C ~ +85°C |
| Humidity | 5%~95%, Non-condensing |
| Vibration | Random Vibration 5.35grms, 3 Axis |
| Shock | Half-sine Wave, 40g/11ms, 3 Axis 6 Direction |
| Optics |
| Optional Lens | Fixed Focus Athermal: 19mm/25mm |
Industrial Applications
The PLU1212 infrared imaging module is widely used in Security &
Monitoring, Outdoors, Firefighting & Rescue, Law Enforcement &
Rescue, ADAS, UAV Payloads etc.
Exhibitions
FAQs
1.What is infrared thermography?
Thermography is a new and effective technology of non-invasive
diagnostic method based on object surface temperature detection.
The infrared (IR) radiation emitted from an object is recorded and
visualized in the form of a temperature distribution map.
2. What can the infrared thermography be used for?
The infrared thermal image can be used to perform home inspections,
determine structural defects, electrical faults, mechanical faults,
physiological changes in people & animals and much more.
3.What are the advantages of infrared thermography?
For the non-destructive test, it is simple to test and quick to
response without damage, which results in saving costs, increasing
work efficiency, reducing manpower and equipment depreciation.
For the medical thermography, it is very efficient to find the
hidden problems in human body, 100% safe without radiation and
pain, which is an ideal tool for early health screening.
